Novelis aluminium illuminates Paris’ Milky Way

In the southeast of Paris in Lieusaint, in the heart of Carré Sénart, the Théâtre-Sénart was built as a new cultural center.

Energy-efficient and sustainable design concept

On a total area of about 10,600 square meters and with a height of about 29 meters the new landmark of Carré Sénart rises into the French sky.

With an investment of 43.3 million Euro the architects Chaix & Morel et Associés succeeded in creating a building which combines sustainability, energy efficiency and design. Due to a special lighting and ventilation system, no additional cooling air conditioning or further light sources are needed even on hot and dark days. Furthermore, the technical installations and ventilation systems are hidden behind the aluminum façade that surprises with its striking and flowing forms.

© AACMA/11h45

Pre-painted and perforated aluminium façade shines day and night

The rear-ventilated façade consists of perforated and punched aluminium panels with a grid dimension of 1500mm x 1500mm. Further perforations of 100mm x 100mm and 50mm x 50mm and square punched holes create an apparently random sheet pattern. The overall façade shows eight different sheet design variations. Due to its’ strength even when perforated, the Novelis AIMg3-alloy façade sheet is able to support a high span width. The building skin consisting of 2mm ff2® coil-coated aluminium in the colour shade “sunrise silver” shines day and night. With LED lights integrated into the façade – the futuristic building shines like the Milky Way.

The aluminium panels’ with high-quality PvdF surface finish been proven to be a viable solution for building projects worldwide because of its weather resistance even in extreme climates. Despite the uncoated edges resulting from the punched holes, the material is unaffected by corrosion

© AACMA/11h45

Awarded at the Trophées Eiffel 2016

In October 2016, at the Trophées Eiffel 2016, a national award ceremony for outstanding French architecture, the architectural masterpiece Théâtre-Sénart was awarded with the jury price.

Come and see us at the BAU 2017 exhibition, be inspired by innovative anodised or pre-painted aluminium surfaces for attractive architecture.

Hall B1, Booth 131
